Main Features

• Compact HDTV standard lens
• Digital Drive Unit
• X-Element & Power Optical System
• Equipped with Canon’s original Rotary Encoder Device.
• Shoretst M.O.D. among the counterparts

Zoom Ratio
17x

Built-in Extender
2.0x

Range of Focal Length
7.6-130mm
(with Extender)
15.2-260mm (2.0x)

Maximum Relative Aperture
1:1.8 at 7.6-97.5mm
1:2.4 at 130mm
(with Extender)
1:3.6 at 15.2-195mm (2.0x)
1:4.8 at 260mm (2.0x)

Angular Field of View(with Extender)
4:3 Aspect Ratio (8.8 x 6.6mm)
60.1° x 46.9° at 7.6mm
3.9° x 2.9° at 130mm
32.3° x 24.5° at 15.2mm (2.0x)
1.9° x 1.5° at 260mm (2.0x)

16: 9 Aspect Ratio(9.6 x 5.4mm)
64.6° x 39.1° at 7.6mm
4.2° x 2.4° at 130mm
35.1° x 20.1° at 15.2mm (2.0x)
2.1° x 1.2° at 260mm (2.0x)

Minimum Object Distance (M.O.D)
0.56m (10mm with Macro)

Object Dimensions at M.O.D.(with Extender)
4:3 Aspect Ratio(8.8 x 6.6mm)
59.9 x 44.9cm at 7.6mm
3.7 x 2.8cm at 130mm
30.0 x 22.5 cm at 15.2mm (2.0x)
1.9 x 1.4cm at 260mm (2.0x)

16:9 Aspect Ratio (9.6 x 5.4mm)
65.4 x 36.8 cm at 7.6mm
4.0 x 2.3 cm at 130mm
32.7 x 18.4 cm at 15.2 mm (2.0x)
2.0 x 1.2 cm at 260mm (2.0x)

Macro
Yes

Size (W x H x L)
164 x 106.5 x 206.4mm

Weight (Approx.)
1.64kg (3.56lbs)/1.72kg (3.78lbs)
